Water Tap

Why choose us?

1. Food grade material guarantee

AISI 304 stainless steel (GB/T 3280 standard), nickel content 8-10.5%

NSF/ANSI 61 Drinking water safety certification, lead content ≤0.1%

Corrosion resistance: Salt spray test ≥1000 hours (ASTM B117)

2. Precision fluid structure design

Flow path roughness Ra≤0.8μm (after electrolytic polishing), water resistance is reduced by 30%

Spool fitting surface accuracy H7/g6, sealing ≤0.1ml/min (EN 817 standard)

3. Ergonomics and aesthetics

Surface treatment optional:

Mirror polishing (Ra≤0.05μm)

Brushed finish (240 mesh, fingerprint proof)

PVD plating (Champagne gold/Gun grey, wear Class 4)

4. Strict hygiene certification

Meets EN 200 faucet standards

ISO 4531 Heavy metal migration test

Product introduction

This AISI304 stainless steel faucet casting is made of food-grade 304 stainless steel (GB/T 3280 standard), with a 1.2mm thin-wall structure (porosity ≤0.3%) achieved by 7 layers of silica sol precision casting, and the flow channel is electrolytically polished to Ra≤0.8μm to reduce water resistance by 30%. The product is equipped with Swiss TORNOS lathe machining (thread 6H/6g class) and five-axis finishing milling (sealing surface flatness ≤0.02mm), and has passed 1000 hours of salt spray testing and 50,000 switch life tests (EN 817).

Our advantage

1. High dense material system

With A380/ADC12 (GB/T 15115) and AlSi10Mg (EN AC-43000), excellent fluidity (silicon content 9-12%)

Vacuum die casting density ≥99.8% (X-ray porosity ≤0.2%)

2. Thin-walled complex structure

The minimum wall thickness is 0.6mm (typical 1.2-2.5mm), and the maximum projected area is 800cm²

It can integrate heat fin (spacing ≥1.2mm), threaded inserts and other functional structures

3. Multi-industry applications

Automobile: New energy motor housing (IP67 protection, 40% weight reduction)

Electronics: 5G base station radiator (thermal conductivity ≥120W/m·K)

4. Strict certification guarantee

Provide die casting process parameters report + X-ray inspection results (ASTM E505)

Complies with IATF 16949 automotive industry standard

Detail data

FAQ

1.What is the Minimum Order Quantity?

5~1000 pcs. And we also accpet sample orders.

2. Can you manufacture according to customer's samples?

According to samples, we can make drawing, tooling and sample

3.How long will it take to make new samples according to customer's drawing or sample?

Totally 20 days. 10 days for tooling and another 10 days for sample.
