Why choose us?
1. Precision die casting technology
Cold chamber die casting machine (280T~2000T), mold locking accuracy ±0.03mm, to ensure product size stability (CT6~CT7, ISO 8063).
Vacuum assisted die casting (optional), reduce porosity to ≤1%, improve casting density, suitable for parts with high air tightness requirements (such as pump shell, valve body).
2. Intelligent mold and simulation optimization
3D mold FLOW channel analysis (using MAGMAsoft/FLOW-3D®) to optimize the pouring system and reduce defects such as cold insulation and shrinkage.
Precise control of mold temperature (±5℃), prolong mold life (≥ 150,000 mold times), ensure batch consistency.
3. Efficient post-processing & testing
CNC finishing: five-axis linkage machining center guarantees key dimensional tolerance of ±0.05mm.
Full inspection system: X-ray flaw detection (detection of internal defects), coordinate measurement (CMM), salt spray testing to ensure compliance with customer specifications (e.g. ISO 9001, IATF 16949).
Product introduction
We use 316/316L corrosion resistant stainless steel, through the silica sol investment casting process to manufacture fire valves, joints and other key components, the product size accuracy of CT5 level (±0.15mm), through 1.5 times of working pressure test and 2000 hours of salt spray test. Support fast proofing (7-10 days), UL/FM certified, high pressure, corrosion resistant precision casting solutions for fire systems.
Our advantage
1. High strength and lightweight structure
ADC12 aluminum alloy (in accordance with JIS H5302 standard), with excellent casting fluidity, tensile strength ≥230MPa, yield strength ≥150MPa, density only 2.7g/cm³, weight reduction than steel more than 60%, suitable for power tools, pump shells and other applications requiring light weight and high strength.
2. High precision complex structure molding
The die-casting process can produce thin wall parts with a wall thickness of 1.5-5mm and a minimum aperture of ±0.1mm, reducing the need for subsequent machining and reducing the overall cost.
Suitable for complex geometric shapes (such as fins, stiffeners, threaded inserts).
3. Excellent surface quality
Die casting surface roughness Ra3.2~6.3μm, support subsequent sandblasting, anodizing, electrophoresis, powder spraying and other processing, improve corrosion resistance and beauty.
4. Corrosion resistance & high temperature resistance
ADC12 alloy has good corrosion resistance, salt spray test (ASTM B117) up to 500 hours without red rust, and can withstand short-term operating temperature **≤200℃**.
Detail data
Application | Machinery Parts |
Material Type | Aluminum |
Standard | CE, RoHS, ISO 9001:2000 |
Surface Preparation | Electroplating |
Machining | Aluminum Die Casting |
Weight | 0.5kg~50kg |
FAQ
1.What is the Minimum Order Quantity?
5~1000 pcs. And we also accpet sample orders.
2. Can you manufacture according to customer's samples?
According to samples, we can make drawing, tooling and sample
3.How long will it take to make new samples according to customer's drawing or sample?
Totally 20 days. 10 days for tooling and another 10 days for sample
