Lost Wax Investment Casting

Why choose us?

1. Material system covering

Stainless steel: 316L (ASTM A743, 10 times more corrosion resistance than 304)

Alloy steel: ZG270-500 (tensile ≥500MPa, impact work ≥27J)

Special alloy: Cobalt-Chrome-molybdenum (ASTM F75, Biocompatibility certified)

2. Micron precision molding

Minimum wall thickness 0.5mm, minimum aperture φ0.8mm

Dimensional accuracy CT4-CT5 class (ISO 8062), surface roughness Ra≤1.6μm

3. Integration of complex structures

Casting 0.3mm precision mesh, spiral channel, shaped surface

NADCAP Heat treatment certification + PED 2014/68/EU certificate

Meets FDA 21 CFR 177.1520 food grade standard

Product introduction

This precision investment casting is made of 316L stainless steel, ZG270-500 alloy steel and other high-quality materials, through 9 layers of silica sol composite shell (temperature ≥1700℃) and vacuum induction melting (oxygen content ≤30ppm) process, to achieve 0.5mm ultra-thin wall complex structure molding (CT4-CT5 level accuracy). Products are densified by hot isostatic pressing (1200℃/150MPa) and five-axis laser finishing (±0.005mm). Key components such as aviation turbine blades (φ1.2mm cooling channel) and medical implants (porosity ≤0.1%) are strictly inspected by industrial CT (20μm resolution). The monthly production capacity is 50 tons. Supports single crystal/polycrystal process selection and fast sample delivery in 12-15 business days.

Our advantage

1. Composite shell making technology

Silica sol + fused corundum 9 layers coating, type shell temperature ≥1700℃

Digital slurry control (viscosity deviation ±2%)

2. Ultra-pure melting

Vacuum induction melting (oxygen content ≤30ppm)

Ceramic filter (aperture 0.8mm) dual purification

3. Directional solidification technology

Liquid metal cooling (LMC) system, grain orientation deviation ≤5°

Single crystal casting success rate ≥90% (aviation blade special)

4. Intelligent post-processing

Hot isostatic pressing (HIP) : 1200℃/150MPa, resulting in a density of ≥99.98%

Five-axis laser finishing: Feature dimension accuracy ±0.005mm

Detail data

FAQ

1.What is the Minimum Order Quantity?

5~1000 pcs. And we also accpet sample orders.

2. Can you manufacture according to customer's samples?

According to samples, we can make drawing, tooling and sample

3.How long will it take to make new samples according to customer's drawing or sample?

Totally 20 days. 10 days for tooling and another 10 days for sample.
