Why choose us?
1. Lost wax casting process
Silica sol precision shell (7-9 layers)
Medium temperature wax molding system
Vacuum assisted pouring
Argon shielded melting
2. Sand casting process
Resin sand/water glass sand modeling
3D printing sand mold technology (optional)
Step pouring system
Intelligent pouring control
3. Post-processing technology
Vibration aging
Sand blasting/shot blasting
Precision machining equipment
Heat treatment (normalizing, quenching, etc.)
Product introduction
We provide double process of lost wax casting and sand casting, supporting carbon steel, stainless steel, aluminum alloy and other materials, product dimensional accuracy up to CT6 (ISO 8062), surface finish Ra6.3-12.5μm. Suitable for all kinds of mechanical parts customization, through the ISO 9001 quality certification, to provide equipment manufacturers from design to mass production of one-stop precision casting services.
Our advantage
1. Diversified material selection
Carbon steel series: ZG200-400, ZG270-500 (GB/T 11352)
Stainless steel Series: 304, 316 (ASTM A743)
Aluminum alloy series: A356, ZL104 (GB/T 1173)
Special alloy: can be customized according to demand
2. Precision manufacturing parameters
Dimensional accuracy:
Lost wax casting: CT4-6 grade (±0.1mm/m)
Sand casting: CT6-8 grade (±0.3mm/m)
3. Surface roughness:
Lost wax casting: Ra3.2-6.3μm
Sand casting: Ra12.5-25μm
Weight range: 0.1kg-200kg
4. Typical application components
√ Hydraulic system: valve body, pump casing
√ Construction machinery: gear box, connecting parts
√ Industrial equipment: bearing seat, transmission parts
√ Automation equipment: robotic arm joint
Detail data
Application | Machinery Parts |
Material Type | Stainless steel |
Standard | CE, RoHS, ISO 9001:2000, ISO 9001:2008 |
Kind | Stainless Steel Casting |
Molding Technics | Casting |
Weight | 0.5kg~50kg |
FAQ
1.What is the Minimum Order Quantity?
5~1000 pcs. And we also accpet sample orders.
2. Can you manufacture according to customer's samples?
According to samples, we can make drawing, tooling and sample
3.How long will it take to make new samples according to customer's drawing or sample?
Totally 20 days. 10 days for tooling and another 10 days for sample
