Why choose us?
1. Precision casting system
Silica sol investment casting (9-layer shell)
Vacuum induction melting (1600℃±20℃)
Special feeding technology for tooth shape parts
Argon shielded casting
2. Tooth strengthening process
Local high frequency hardening
Cryogenic treatment (-196℃)
Shot peening
Precision grinding of tooth surface
3. Quality inspection system
100% X-ray Inspection (ASTM E505)
Tooth shape coordinate detection (accuracy ±0.02mm)
Hardness gradient test
Salt spray accelerated corrosion test
Dynamic load testing (100,000 cycles)
Product introduction
We use ASTM certified 316L stainless steel, through nine layers of silica sol investment casting process to manufacture high-precision tooth parts, teeth hardened by high frequency hardening HRC45-50, pitch accuracy ±0.05mm. The product has passed 3,000 hours of salt spray testing and 100,000 times of dynamic load verification, with tensile strength ≥485MPa. Specialized for critical components such as gear gears and Marine winches, DNV/GL certified support ensures excellent corrosion and wear resistance in harsh Marine environments.
Our advantage
1. High quality material system
Available in 304 stainless steel (ASTM A743 CF8m) and special alloy steel
Material characteristics: High temperature resistance to 800℃, excellent corrosion resistance
Mechanical properties: Tensile strength ≥515MPa, elongation ≥30%
TS16949 material certification in automotive industry
2. Precision manufacturing parameters
Dimensional accuracy CT5 (ISO 8062 standard)
Minimum wall thickness 1.2mm
Surface roughness Ra3.2μm (polished to Ra0.8μm)
Single weight range: 50g-15kg
3. Professional application field
√ Automobile engine: turbine housing, sensor seat
√ Motorcycle parts: clutch housing, support
√ Industrial motors: end caps, connectors
√ Hydraulic system: valve body, pump casing
Detail data
Application | Hardware |
Material Type | Stainless steel |
Standard | ISO 9001 2015 |
Molding Technics | Lost Wax Casting |
Casting | Investment Casting |
Weight | 0.5kg~50kg |
FAQ
1.What is the Minimum Order Quantity?
5~1000 pcs. And we also accpet sample orders.
2. Can you manufacture according to customer's samples?
According to samples, we can make drawing, tooling and sample
3.How long will it take to make new samples according to customer's drawing or sample?
Totally 20 days. 10 days for tooling and another 10 days for sample
