Why choose us?
1. Precision casting system
Silica sol-ethyl silicate composite shell (9 layers)
Vacuum pressure pouring technology
Shell intelligent roasting system (1050℃±10℃)
Argon shielded melting (1600-1650℃)
2. Special surface treatment
Electrolytic polishing (according to ASTM B912)
Nano-coating anti-fouling treatment (optional)
Laser etched logo
Vibration stress relief
3. Full-dimensional detection system
100% Penetration Testing (PT)
Full size measurement in three coordinates (±0.03mm)
Salt spray test (3000 hours)
Seismic test (Class 8 intensity simulation)
Fatigue test (500,000 cycles)
Product introduction
We use 304/316/2205 biphase steel, through the nine-layer silica sol precision casting process, the product size accuracy of CT5 (ISO 8062), the minimum wall thickness of 1.5mm, the surface treatment is optional wire/mirror (Ra0.8μm). After 3000 hours of salt spray test and 500,000 fatigue tests, static load ≥1500kg. It is professionally used in curtain wall system, bridge engineering and other fields, providing CE/EN1090 certification support to ensure the structural safety and long-term durability of building hardware.
Our advantage
1. Engineering grade material system
Full range of 304/316/2205 duplex steel options available
Meets ASTM A276/A479 building standards
Weather resistance: Passed 5000 hours accelerated aging test
Mechanical strength: Tensile strength ≥515MPa (316 material)
2. Precise structural characteristics
Dimensional accuracy CT5 (ISO 8062)
Minimum wall thickness 1.5mm (structural parts)
Surface treatment: Wire drawing/mirror/sandblasting (Ra0.8-3.2μm)
Load capacity: Static load ≥1500kg
3. Professional application scenarios
√ Curtain wall system: corner connector/load-bearing bracket
√ Outdoor facilities: guardrail base/hinge components
√ Architectural decoration: Art castings/custom hardware
√ Bridge engineering: seismic connection components
Detail data
Application | Hardware |
Material Type | Stainless steel |
Standard | CE, RoHS, ISO 9001:2000 |
Molding Technics | Gravity Casting |
Casting | Investment Casting |
Weight | 0.5kg~50kg |
FAQ
1.What is the Minimum Order Quantity?
5~1000 pcs. And we also accpet sample orders.
2. Can you manufacture according to customer's samples?
According to samples, we can make drawing, tooling and sample
3.How long will it take to make new samples according to customer's drawing or sample?
Totally 20 days. 10 days for tooling and another 10 days for sample
