Large Forging Steel

Why choose us?

1. Intelligent free forging system

8000T hydraulic forging press: The deformation rate is 0.05-2m/s stepless adjustable

Intelligent operator: forging accuracy ±3mm/ m (equipped with laser positioning)

2. Special heating technology

Aluminum alloy: gas furnace precise temperature control (±5℃) to prevent overburning

Copper alloy: medium frequency induction heating (850±10℃), oxide skin ≤0.3%

3. Organization control process

Multi-direction forging method: forging ratio ≥6:1, grain size ≥ASTM 5 class

Gradient heat treatment: shaft core toughness/surface hardness differential control

4. Digital detection

Phased array Ultrasound (PAUT) : Detection of Φ1mm defects (EN 10228-3)

Residual stress analysis: X-ray diffraction (stress value ≤15%σs)

Product introduction

This multi-metal free forging is made of 6082-T6 aluminum alloy (tensile ≥310MPa), H62 brass and duplex steel 2205, and is achieved by 8000T hydraulic forging press with super-size forging (Max. Ø1500mm×8m, weighing 5 tons per piece). The product is optimized by multi-directional forging (forging ratio ≥6:1) and gradient heat treatment, and key components such as ship propeller shafts (fatigue life ≥10⁷ times) are tested by phased array ultrasound (EN 10228-3).

Our advantage

1. All metal material covering

Aluminum alloy: 6082-T6 (tensile ≥310MPa), 7075 (hardness ≥HB150)

Copper alloy: H62 brass (conductivity ≥28%IACS), aluminum bronze (wear resistance increased by 3 times)

Stainless steel: 304 (corrosion resistance), 17-4PH (aging hardness HRC40-45)

2. Super size forging ability

Maximum single weight 5 tons (aluminum alloy) / 3 tons (steel)

Forgable diameter Ø200-1500mm, length ≤8m

3. Industry customized solutions

Ship: Propeller shaft (Cu3 nickel-aluminum bronze, fatigue life ≥10 Guess)

Power: Generator rotor shaft (34CrMo1A, UT test level 1)

Chemical: acid resistant pump body (duplex steel 2205, Cl-corrosion resistant)

4. Strict certification system

Provision of material traceability reports (EN 10204 3.2)

ABS/DNV/GL Classification Society certification (optional)

Detail data

FAQ

1.What is the Minimum Order Quantity?

5~1000 pcs. And we also accpet sample orders.

2. Can you manufacture according to customer's samples?

According to samples, we can make drawing, tooling and sample

3.How long will it take to make new samples according to customer's drawing or sample?

Totally 20 days. 10 days for tooling and another 10 days for sample.
