Why choose us?
1. Large size processing ability
Maximum turning diameter Ø2000mm, milling stroke 3000×1500×800mm
Typical processing weight ≤8 tons (aluminum parts) / ≤5 tons (steel parts)
2. Multi-material precision machining
Aluminum alloy: 5083/7075 (aerospace grade, surface roughness Ra≤1.6μm)
Stainless steel: 304/316L (medical grade, straightness ≤0.05mm/m)
Special metals: Titanium alloy (Gr5), superalloy (Inconel 718)
3. Industry customized solutions
Energy equipment: wind power gearbox housing (flatness ≤0.1mm)
Rail transit: bogie components (fatigue life ≥10⁷ cycles)
Semiconductor: vacuum chamber flange (helium leak detection rate ≤5×10⁻⁹Pa·m³/s)
4. Strict quality system
Laser tracker detection (large size accuracy ±0.05mm)
Ultrasonic thickness measurement (wall thickness tolerance ±0.1mm)
Provide material 3.1/3.2 certification report
Product introduction
This large CNC machining service is equipped with a 5-meter vertical lathe and gantry machining center, with superior machining capacity (maximum turning diameter of Ø2000mm, workpiece weight ≤8 tons), and can handle a variety of materials such as aluminum alloy (5083/7075), stainless steel (304/316L) and titanium alloy. Through constant temperature workshop (20±1℃) and laser compensation technology to ensure large size accuracy (±0.05mm), provide wind power gearbox, ship thrusters and other large parts processing, with laser quenching (hardness ≥HRC55) and other special processes to meet the energy, rail transit and other industries of heavy precision machining needs.
Our advantage
1. Heavy CNC equipment cluster
5 m vertical lathe (spindle torque 6000Nm)
Gantry machining center (positioning accuracy 0.015mm/ full length)
Deep hole drilling system (Max hole depth 3m, straightness 0.1mm/m)
2. Special process combination
Large surface finishing milling: corrugability ≤0.02mm (using static guide milling head)
Heavy thread processing: M120×4 super thread (CNC indexing)
Asymmetric debalancing: Residual unbalance ≤G2.5 level
3. Temperature compensation technology
Workshop constant temperature control (20±1℃)
Online laser compensation for thermal deformation (compensation accuracy ±0.01mm)
4. Surface engineering treatment
Large shot peening: Almen strength 0.3-0.5mmA
Local hardening: laser hardening hardness ≥HRC55
Anti-rust packaging: VCI gas phase anti-rust film (Marine protection)
Detail data
Application | Metal Recycling Machine, Metal Cutting Machine, Metal Straightening Machinery, Metal Spinning Machinery, Metal Processing Machinery Parts, Metal forging Machinery, Metal Engraving Machinery, Metal Drawing Machinery, Metal Coating Machinery, Metal Casting Machinery |
Material Type | Steel, Alloy, Aluminum, Iron |
Standard | CE, RoHS, GS, ISO9001, SGS |
Surface Treatment | Electroplating |
Machining Method | CNC Machining |
Weight | 0.5kg~50kg |
FAQ
1.What is the Minimum Order Quantity?
5~1000 pcs. And we also accpet sample orders.
2. Can you manufacture according to customer's samples?
According to samples, we can make drawing, tooling and sample
3.How long will it take to make new samples according to customer's drawing or sample?
Totally 20 days. 10 days for tooling and another 10 days for sample.
